CEP83A3

cep83a3, N-Channel Enhancement Mode Field Effect Transistor, 10 V, 100 A, TO, Chino-Excel Technology

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.30~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 500 :	2.40 / Piece
501 ~ 1000 :	2.30 / Piece

PartNumber:: CEP83A3

Brand:: Chino-Excel Technology - CET | Pack: | D/C:

Availability:: Supply Ability: 8000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-18

From Other Seller

Part Number:CEP83A3
US $2.30 - 2.50
Quantity:

piece

Product Summary

The cep83a3 is an N-Channel Enhancement Mode Field Effect Transistor.

Parametrics

cep83a3 absolute maximum ratings: (1)Drain-Source Voltage, VDS: 30 V; (2)Gate-Source Voltage, VGS: ±20 V; (3)Drain Current-Continuous, ID: 100 A; (4)Drain Current-Pulsed, IDM: 400 A; (5)Maximum Power Dissipation @ TC = 25 ℃, Derate above 25 ℃, PD: 100 W, 0.67 W/℃; (6)Single Pulsed Avalanche Energy, EAS: 875 mJ; (7)Single Pulsed Avalanche Current, IAS: 35 A; (8)Operating and Store Temperature Range TJ,Tstg: -55 to 175 ℃.

Features

cep83a3 features: (1)30 V, 100 A, RDS(ON) = 5.3 mΩ, @VGS = 10 V; (2)Super high dense cell design for extremely low RDS(ON); (3)High power and current handing capability; (4)Lead free product is acquired; (5)TO-220 & TO-263 package.
