Product Summary

The cx5032sb13560f0fljz1 is a surface mount type crystal unit. The applications of the cx5032sb13560f0fljz1 include Digital Electronics, Audio-Visual, Office Equipment.

Parametrics

cx5032sb13560f0fljz1 absolute maximum ratings: (1)Frequency Range: 13560 to 60000 kHz; (2)Overtone Order: fundamental; (3)Frequency Tolerance: ±50; (4)Frequency Temp. Characteristics: ±50; (5)Motional Series Resistance: table 1 ohm; (6)Level of Drive: table 2 μw; (7)Load Capacitance: 8 pF; (8)Operating Temp. Range: -10 to 70 ℃; (9)Storage Temp. Range: -40 to 85 ℃.

Features

cx5032sb13560f0fljz1 features: (1)Crystal unit for audio-visual, office equipment; (2)Ultra-miniature and low profile (2.5×2.0×0.45mm); (3)Ceramic package; (4)A lead free product; (5)Reflow compatible.

Diagrams

cx5032sb13560f0fljz1 block diagram
