EL7532IYZ-T7

el7532iyz-t7, step-down regulator, 6.5V, 2.4A, 1.5MHz, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.20~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 800 :	2.40 / Piece
801 ~ 1600 :	2.20 / Piece

PartNumber:: EL7532IYZ-T7

Brand:: ELM Electronics - ELM | Pack: | D/C:

Availability:: Supply Ability: 8000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-23

From Other Seller

Part Number:EL7532IYZ-T7
US $2.20 - 2.50
Quantity:

piece

Product Summary

The el7532iyz-t7 is a synchronous, integrated FET 2A step-down regulator with internal compensation. It operates with an input voltage range from 2.5V to 5.5V, which accommodates supplies of 3.3V, 5V, or a Li-Ion battery source. It is available in the 10-pin MSOP package. It is ideal for: (1)PDA and pocket PC computers; (2)Bar code readers; (3)ADSL modems; (4)Portable instruments; (5)Li-Ion battery powered devices; (6)ASIC/FPGA/DSP supplies; (7)Set top boxes.

Parametrics

el7532iyz-t7 absolute maximum ratings: (1)VIN, VDD, POR to SGND: -0.3V to +6.5V; (2)LX to PGND: -0.3V to (VIN + +0.3V); (3)RSI, EN, VO, FB to SGND: -0.3V to (VIN + +0.3V); (4)PGND to SGND: -0.3V to +0.3V; (5)Peak Output Current: 2.4A; (6)Operating Ambient Temperature: -40℃ to +85℃; (7)Storage Temperature: -65℃ to +150℃; (8)Junction Temperature: +125℃.

Features

el7532iyz-t7 features: (1)2A continuous current (from -40°C to +85°C); (2)Less than 0.18 in 2 footprint for the complete 2A converter; (3)Max height 1.1mm MSOP10; (4)1.5MHz (typ.)switching frequency; (5)100ms Power-On-Reset output (POR); (6)Internally-compensated voltage mode controller; (7)Up to 94% efficiency; (8)<1µA shut-down current; (9)Overcurrent and over temperature protection; (10)Pb-free plus anneal available (RoHS compliant).
