FDA69N25

fda69n25, N-Channel UniFET MOSFET, 250 V, 69 A, 1894 mJ, FSC Forest Stewardship Council

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.30~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 500 :	2.40 / Piece
501 ~ 1000 :	2.30 / Piece

PartNumber:: FDA69N25

Brand:: FSC Forest Stewardship Council - FSC | Pack: | D/C:

Availability:: Supply Ability: 8000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-10-21

From Other Seller

Part Number:FDA69N25
US $2.30 - 2.50
Quantity:

piece

Product Summary

The fda69n25 is an N-Channel UniFETTM MOSFET. It is based on planar stripe and DMOS technology. The fda69n25 is tailored to reduce on-state resistance, and to provide better switching performance and higher avalanche energy strength. It is suitable for switching power converter applications such as PFC, FPD TV power, ATX and lighting ballasts.

Parametrics

fda69n25 absolute maximum ratings: (1)VDSS Drain-Source Voltage: 250 V; (2)VDS(Avalanche) Repetitive Avalanche Voltage: 300 V; (3)ID Drain Current Continuous (TC = 25℃): 69 A; (4)ID Drain Current Continuous (TC = 100℃): 44.2 A; (5)IDM Drain Current Pulsed: 276 A; (6)VGSS Gate-Source Voltage: ± 30 V; (7)EAS Single Pulsed Avalanche Energy: 1894 mJ; (8)IAR Avalanche Current: 69 A; (9)EAR Repetitive Avalanche Energy: 48 mJ; (10)dv/dt Peak Diode Recovery dv/dt: 4.5 V/ns; (11)PD Power Dissipation (TC = 25℃): 480 W; (12)PD Power Dissipation Derate above 25℃: 3.84 W/℃; (13)TJ, TSTG Operating and Storage Temperature Range: -55 to +150℃; (14)TL Maximum lead temperature for soldering purposes, 1/8" from case for 5 seconds: 300℃.
