FQNL2N50BTA

fqnl2n50bta, N-Channel enhancement mode power field effect transistors, 500 v, 1.4 a, HannStar Display Corporation

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.20~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 800 :	2.40 / Piece
801 ~ 1600 :	2.20 / Piece

PartNumber:: FQNL2N50BTA

Brand:: Fairchild Semiconductor - Fairchild | Pack: | D/C:

Availability:: Supply Ability: 8000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-23

From Other Seller

Part Number:FQNL2N50BTA
US $2.20 - 2.50
Quantity:

piece

Product Summary

The fqnl2n50bta is an N-Channel enhancement mode power field effects transistors which is produced using Fairchild’s proprietary, planar stripe, DMOS technology. The fqnl2n50bta advanced technology has been especially tailored to minimize on-state resistance, provide superior switching performance, and withstand high energy pulse in the avalanche and commutation mode. The fqnl2n50bta is well suited for high efficiency switch mode power supply, power factor correction, electronic lamp ballast based on half bridge.

Parametrics

fqnl2n50bta absolute maximum ratings: (1)VDSS: 500 v; (2)ID: 0.35 a; (3)IDM: 1.4 a; (4)VGSS: ± 30 v; (5)IAR: 0.35 a; (6)EAR: 0.15 mj; (7)dv/dt: 4.5 v/ns; (8)PD: 1.5 w; (9)TJ, TSTG: -55 to 150 ℃; (10)TL: 300 ℃.

Features

fqnl2n50bta features: (1)0.35A, 500V, RDS(on) = 5.3 ＠VGS = 10 V; (2)Low gate charge ( typical 6.0 nC); (3)Low Crss ( typical 4.0 pF); (4)Fast switching; (5)Improved dv/dt capability.
