FXMA108BQX

fxma108bqx, translator, 8000 V, -50 mA, QFN-24

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.30~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 500 :	2.40 / Piece
501 ~ 1000 :	2.30 / Piece

PartNumber:: FXMA108BQX

Brand:: Fairchild Semiconductor - Fairchild | Pack: | D/C:

Availability:: Supply Ability: 8000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-18

From Other Seller

Part Number:FXMA108BQX
US $2.30 - 2.50
Quantity:

piece

Product Summary

The fxma108bqx is a configurable dual-voltage supply translator designed for both uni-directional and bidirectional voltage translation between two logic levels. The device allows translation between voltages as high as 5.5V to as low as 1.65V. The A port tracks the VCCA level and the B port tracks the VCCB level. This allows for bi-directional voltage translation over a variety of voltage levels: 1.8V, 2.5V, 3.3V, and 5.0V. It is ideal for: Cell Phones, PDA, Digital Camera, Portable GPS, and Storage

Parametrics

fxma108bqx absolute maximum ratings: (1)VCC Supply Voltage VCCA: -0.5 to 7.0 V; (2)VIN DC Input Voltage I/O Side A and B: -0.5 to 7.0 V; (3)VO Output Voltage Output 3-State: -0.5 to 7.0V; (4)IIK DC Input Diode Current VIN < 0V: -50 mA; (5)IOK DC Output Diode Current VO < 0V: -50 mA; (6)ICC DC VCC or Ground Current (Per Supply Pin): ±100 mA; (7)TSTG Storage Temperature Range: -65 +150 °C; (8)ESD Electrostatic Discharge Capability Human Body Model, JESD22- A114, and Mil Std 883e 3015.7 B Port I/O to GND: 8000 V.

Features

fxma108bqx features: (1)Bi-Directional Interface between Two Levels from 1.65V to 5.5V; (2)Fully Configurable: Inputs and Outputs Track VCC; (3)Non-Preferential Power-Up; Either VCC may be Powered-Up First; (4)Outputs Remain in 3-State Until Active VCC Level is Reached; (5)Outputs Switch to 3-State if Either VCC is at GND; (6)Power-Off Protection; (7)Bus Hold On Data Inputs Eliminates the Need for Pull-Up Resistors; (8)Control Input (/OE)is Referenced to VCCA Voltage; (9)Packaged in 20-Terminal DQFN; (10)Direction Control Not Needed; (11)80Mbps Throughput when Translating between 2.5V and 5.0V.
