IRFP250NPBF

hexfet power mosfet, 21A, ±20V, 21mJ, TO-247AC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.20~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 800 :	2.40 / Piece
801 ~ 1600 :	2.20 / Piece

PartNumber:: IRFP250NPBF

Brand:: International Rectifier - IR | Pack: | D/C:

Availability:: Supply Ability: 8000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-23

From Other Seller

Part Number:IRFP250NPBF
US $2.20 - 2.50
IRFP250NPBF

US $0.80 - 0.85 / Piece
(0) Remove
Quantity:

piece

Product Summary

The irfp250npbf is a hexfet power mosfet. The irfp250npbf is from International Rectifier utilize advanced processing techniques to achieve extremely low on-resistance per silicon area. This benefit, combined with the fast switching speed and ruggedized device design that the irfp250npbf is well known for, provides the designer with an extremely efficient and reliable device for use in a wide variety of applications. The TO-247 package of the irfp250npbf is preferred for commercial-industrial applications where higher power levels preclude the use of TO-220 devices.

Parametrics

irfp250npbf absolute maximum ratings: (1) Continuous Drain Current, VGS@10V, ID@Tc=25°C: 30A; (2) Continuous Drain Current, VGS@10V, ID@Tc=100°C: 21A; (3) Pulsed Drain Current IDM: 120A; (4) Power Dissipation, PD@Tc=25°C: 214W; (5) Linear Derating Factor: 1.4W/°C; (6) Gate-to-Source Voltage VGS: ±20V; (7) Single Pulse Avalanche Energy EAS: 315mJ; (8) Avalanche Current IAR: 30A; (9) Repetitive Avalanche Energy EAR: 21mJ; (10) Peak Diode Recovery dv/dt: 8.6V/ns; (11) Operating Junction and Storage Temperature Range TJ, TSTG: -55 to +175°C; (12) Soldering Temperature, for 10 seconds: 300°C (1.6mm from case) .

Features

irfp250npbf features: (1) Advanced Process Technology; (2) Dynamic dv/dt Rating; (3) 175°C operating temperature; (4) Fast Switching; (5) Fully Avalanche Rated; (6) Ease of Paralleling; (7) Simple Drive Requirements; (8) Lead-Free.
