ISD17240PY

isd17240py, single-chip multi message voice record/playback device, International Software Development (Shenzhen) Co. Ltd., -0.3V to +7.0V, 4 kHz to 12 kHz, PDIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.30~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 500 :	2.40 / Piece
501 ~ 1000 :	2.30 / Piece

PartNumber:: ISD17240PY

Brand:: International Software Development (Shenzhen) Co. Ltd. - ISD | Pack: | D/C:

Availability:: Supply Ability: 8000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-10-21

From Other Seller

Part Number:ISD17240PY
US $2.30 - 2.50
Quantity:

piece

Product Summary

The isd17240py is a high quality, fully integrated, single-chip multi message voice record and playback device ideally suited to a variety of electronic systems. The message duration is user selectable in ranges from 26 seconds to 120 seconds, depending on the specific device. The sampling frequency of the isd17240py can also be adjusted from 4 kHz to 12 kHz with an external resistor, giving the user greater flexibility in duration versus recording quality for each application. Operating voltage spans a range from 2.4 V to 5.5 V to ensure that the isd17240py is optimized for a wide range of battery or line-powered applications.

Parametrics

isd17240py absolute maximum ratings: (1)Junction temperature: 150℃; (2)Storage temperature range: -65℃ to +150℃; (3)Voltage Applied to any pads: (VSS - 0.3V) to (VCC + 0.3V); (4)Power supply voltage to ground potential: -0.3V to +7.0V; (5)Voltage applied to any pin (Input current limited to +/-20 mA): (VSS – 1.0V) to (VCC + 1.0V).

Features

isd17240py features: (1)level-trigger for recording; (2)edge-trigger for individual message or level-trigger for looping playback sequentially; (3)edge-triggered erase for first or last message or level-triggered erase for all messages; (4)edge-trigger to advance to the next message or fast message scan during the playback; (5)8 levels output volume control; (6)ready or busy status indication; (7)return to the default state; (8)automatic power-down after each operation cycle.
