Product Summary
The lq064v3dg01 is a Color TFT-LCD Module(LCD TV/Digital still camera).
Parametrics
lq064v3dg01 absolute maximum ratings: (1)Display size: 16 [6.4] cm [ "]; (2)No. of pixels: 307 200 pixel; (3)Dot format (H x V): 640 x RGB x 480 dot; (4)Dot pitch (H x V): 0.068 x 0.202 mm; (5)Active area (H x V): 130.6 x 97.0 mm; (6)Brightness: 300 cd/m2; (7)Power consumption: 3.4 W; (8)Outline dimensions (W x H x D): 178.8 x 126.8 x 12.0 mm; (9)Weight: 290 g; (10)Storage temperature: -25 to +70 °C.
Features
lq064v3dg01 features: (1)16 cm [6.4"] display size; (2)Built-in DC/AC converter for backlight drive.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LQ064V3DG01 |
Sharp Microelectronics |
TFT Displays & Accessories 6.4" TFT 640x480 (2 x CCFT) |
Data Sheet |
Negotiable |
|
||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||
|
LQ064A5CG01 |
Sharp Microelectronics |
TFT Displays & Accessories 6.4" Composite NTSC Video Interface |
Data Sheet |
Negotiable |
|
||||||||
 |
LQ064V1DS11 |
Other |
|
Data Sheet |
Negotiable |
|
||||||||
|
LQ064V3DG01 |
Sharp Microelectronics |
TFT Displays & Accessories 6.4" TFT 640x480 (2 x CCFT) |
Data Sheet |
Negotiable |
|
||||||||
|
LQ065T9DR51 |
Sharp Microelectronics |
TFT Displays & Accessories 6.5" AD 6Bit Dig Non-RoHS |
Data Sheet |
Negotiable |
|
||||||||
|
LQ065Y5DG02 |
Sharp Microelectronics |
TFT Displays & Accessories 6.5" 800x480 VGA PC-Wide |
Data Sheet |
Negotiable |
|
||||||||
|
LQ065Y5DG03 |
Sharp Microelectronics |
TFT Displays & Accessories 6.5" 800x480 WVGA |
Data Sheet |
|
|
||||||||
