LQ121S1LG81

lq121s1lg81, TFT-LCD Module, 0 to 6.0 V, 430 to 530 mA, Sharp Electrionic Components

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.30~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 500 :	2.40 / Piece
501 ~ 1000 :	2.30 / Piece

PartNumber:: LQ121S1LG81

Brand:: Sharp Electrionic Components - Sharp | Pack: | D/C:

Availability:: Supply Ability: 8000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-18

From Other Seller

Part Number:LQ121S1LG81
US $2.30 - 2.50
Quantity:

piece

Product Summary

The lq121s1lg81 is a TFT-LCD Module incorporating amorphous silicon TFT. The lq121s1lg81 is composed of a color TFT-LCD panel, drive ICs, control circuit and power supply circuit and a backlight unit.

Parametrics

lq121s1lg81 absolute maximum ratings: (1)Supply voltage, Vcc: 0 to 6.0 V; (2)Input voltage, Vl1: -0.3 to Vcc+0.3 V; (3)Storage temperature, Tstg: -30 to +70 ℃; (4)Operating temperature, Topa: -10 to +65 ℃.

Features

lq121s1lg81 features: (1)Supply voltage, Vcc: +3.0 to +5.5 V; (2)Current dissipation, Icc: 430 to 530 mA; (3)Permissive input ripple voltage, VRP: 100 mVp-p; (4)Input voltage range, VL: 2.4 V; (5)Input voltage low, VIL: 0.8 V; (6)Input voltage high, VIH: 2.1 V; (7)Differential input threshold voltage high, VTH: VCM+100 mV; (8)Differential input threshold voltage low, VTL: VCM-100 mV; (9)Input impedance, RT: 100 Ω; (10)Inpput current low, IOL: -800 uA; (11)Inpput current high, IOH: -10 uA.
