M27W401-80K6

M27W401-80K6, EPROM, 7 V, 4 Mbit, 15 mA, PLCC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.20~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 800 :	2.40 / Piece
801 ~ 1600 :	2.20 / Piece

PartNumber:: M27W401-80K6

Brand:: Advanced Micro Devices - AMD | Pack: | D/C:

Availability:: Supply Ability: 8000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-23

From Other Seller

Part Number:M27W401-80K6
US $2.20 - 2.50
Quantity:

piece

Product Summary

The M27W401-80K6 is a low voltage 4 Mbit EPROM offered in the two ranges UV (ultra violet erase) and OTP (one time programmable). The M27W401-80K6 is ideally suited for microprocessor systems requiring large data or program storage and is organised as 524,288 by 8 bits. The M27W401-80K6 operates in the read mode with a supply voltage as low as 2.7V at –40 to 85°C temperature range. The decrease in operating power allows either a reduction of the size of the battery or an increase in the time between battery recharges.

Parametrics

M27W401-80K6 absolute maximum ratings: (1)Ambient operating temperature (2): –40 to 85 °C; (2)Temperature under bias: –50 to 125 °C; (3)Storage temperature: –65 to 150 °C; (4)Input or output voltage (except A9): –2 to 7 V; (5)Supply voltage: –2 to 7 V; (6)A9 voltage: –2 to 13.5 V; (7)Program supply voltage: –2 to 14 V.

Features

M27W401-80K6 features: (1)2.7V to 3.6V supply voltage in read operation; (2)Access time: 70 ns at VCC = 3.0V to 3.6V; 80 ns at VCC = 2.7V to 3.6V; (3)Pin compatible with M27C4001; (4)Low power consumption: 15 μA Max, standby current; 15 mA Max, active current at 5 MHz; (5)Programming time 100 μs/byte; (6)High reliability CMOS technology 2,000V ESD protection; 200 mA latchup protection immunity; (7)Electronic signature. Manufacturer code: 20h; Device code: 41h; (8)ECOPACK packages available.
