MAX900AEWP

high-speed, low-power voltage comparator, +12V, 500mW, 4mA, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.20~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 800 :	2.40 / Piece
801 ~ 1600 :	2.20 / Piece

PartNumber:: MAX900AEWP

Brand:: Dallas Semiconductor - Maxim | Pack: | D/C:

Availability:: Supply Ability: 8000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-23

From Other Seller

Part Number:MAX900AEWP
US $2.20 - 2.50
Quantity:

piece

Product Summary

The max900aewp is a high-speed, low-power voltage comparator. The max900aewp features differential analog nputs and TTL-logic outputs with active internal pull-ups. The max900aewp is equipped with independent TTL-compatible latch inputs. The max900aewp can be powered from separate analogand digital power supplies or from a single combined supply voltage. Applications of the max900aewp include: High-Speed A/D, Converters, High-Speed V/F converters, Line Receivers, Threshold Detectors, Input Trigger Circuitry, High-Speed Data, Sampling and PWM Circuits.

Parametrics

max900aewp absolute maximum ratings: (1) Analog Supply Voltage (VCC to VEE) : +12V; (2) Digital Supply Voltage (VDD to GND) : +7V; (3) Differential Input Voltage: (VEE - 0.2V) to (VCC + 0.2V) ; (4) Common-Mode Input Voltage: (VEE - 0.2V) to (VCC + 0.2V) ; (5) Latch-Input Voltage: -0.2 to (VDD +0.2V) ; (6) Output Short-Circuit Duration: Indefinite (TO GND), 1 min (To VDD) ; (6) Internal Power Dissipation: 500mW; (7) Derate above +100°C: 10mW/°C; (8) Junction Temperature: -65 to +150°C; (9) Storage Temperature Range: -65 to +150°C; (10) Lead Temperature (soldering, 10s) : +300°C.

Features

max900aewp features: (1) 8ns (typ) Propagation Delay; (2) 18mW/Comparator Power Consumption (+5V, typ) ; (3) Separate Analog and Digital Supplies; (4) Flexible Analog Supply: +5V to +10V or ±5V; (5) Input Range Includes Negative Supply Rail; (6) TTL-Compatible Outputs; (7) TTL-Compatible Latch Inputs (Except MAX901) .
