Product Summary

The qt1101-isg is a self-contained, patented digital controller capable of detecting near-proximity or touch on up to ten electrodes. The qt1101-isg allows electrodes to project independent sense fields through any dielectric such as glass or plastic. This capability of the qt1101-isg coupled with its continuous self-calibration feature can lead to entirely new product concepts, adding high value to product designs. The devices of the qt1101-isg are designed specifically for human interfaces, like control panels, appliances, gaming devices, lighting controls, or anywhere a mechanical switch or button may be found; they may also be used for some material sensing and control applications. The applications of the qt1101-isg include Pointing devices, Remote controls, PC peripherals, Television controls, MP3 players, Mobile phones.

Parametrics

qt1101-isg absolute maximum ratings: (1)Operating temperature, Ta: -40 to +85 ℃; (2)Storage temp, Ts: -50 to +125 ℃; (3)Vdd: -0.3 to +6.0V; (4)Max continuous pin current, any control or drive pin: ±20mA; (5)Short circuit duration to ground or Vdd, any pin: infinite; (6)Voltage forced onto any pin: -0.3V to (Vdd + 0.3) Volts.

Features

qt1101-isg features: (1)Patented charge-transfer design; (2)Ten independent QT sensing fields (keys); (3)2.8V to 5.5V single supply operation; (4)40μA current typ @ 3V in 360ms LP mode; (5)100% autocal for life - no adjustments required; (6)Serial one or two wire interface with auto baud rate; (7)Fully debounced results; (8)Patented AKS Adjacent Key Suppression; (9)Spread spectrum bursts for superior noise rejection; (10)Sync pin for excellent LF noise rejection; (11)‘Fast mode’ for use in slider type applications; (12)RoHS compliant 32-QFN, 48-SSOP packages.
