SKD160/16

skd160/16, Power Bridge Rectifier, 3600 V, 1800 A, Semikron International

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.30~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 500 :	2.40 / Piece
501 ~ 1000 :	2.30 / Piece

PartNumber:: SKD160/16

Brand:: Semikron International - SEMIKRON | Pack: | D/C:

Availability:: Supply Ability: 8000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-18

From Other Seller

Part Number:SKD160/16
US $2.30 - 2.50
Quantity:

piece

Product Summary

The skd160/16 is a Power Bridge Rectifier. The applications of the skd160/16 include Three phase rectifiers for power supplies, Input rectifiers for variable frequency drives, Rectifiers for DC motor field supplies, Battery charger rectifiers.

Parametrics

skd160/16 absolute maximum ratings: (1)ID: 205 A; (2)IFSM: 1800 A; (3)IT: 16200 AS; (4)VF: max.1.65 V; (5)VTO: max. 0.85 V; (6)RT: max. 3 mΩ; (7)IRD: max. 0.5 mA; (8)RTH J-C: 0.65 K/W; (9)RTH C-S: 0.11 K/W; (10)TVJ: -40 to +150 ℃; (11)TSTG: -40 to +125 ℃; (12)VISOL: 3600 V; (13)MS: 5 ± 5% Nm; (14)MT: 5 ± 5% Nm; (15)M: 270 g.

Features

skd160/16 features: (1)Robust plastic case with screw terminals; (2)Large, isolated base plate; (3)Blocking voltage up to 1800 V; (4)High surge currents; (5)Three phase brige rectifier; (6)Easy chassis mounting; (7)UL recognized, file no. E 63532.
