ST62E65CF1

8-bit HCMOS microcontroller, -0.3 to 7.0V, 100mA, st62e65cf1

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.30~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 500 :	2.40 / Piece
501 ~ 1000 :	2.30 / Piece

PartNumber:: ST62E65CF1

Brand:: STMicroelectronics - ST | Pack: | D/C:

Availability:: Supply Ability: 8000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-18

From Other Seller

Part Number:ST62E65CF1
US $2.30 - 2.50
Quantity:

piece

Product Summary

The st62e65cf1 is an 8-bit HCMOS microcontroller, which is targeted at low to medium complexity applications. The st62e65cf1 is based on a building block approach: a common core is surrounded by a number of on-chip peripherals. OTP devices offer all the advantages of user programmability at low cost, which make the st62e65cf1 the ideal choice in a wide range of applications where frequent code changes, multiple code versions or last minute programmability are required.

Parametrics

st62e65cf1 absolute maximum ratings: (1)VDD Supply Voltage: -0.3 to 7.0V; (2)VI, Input Voltage: VSS - 0.3 to VDD + 0.3V; (3)VO, Output Voltage: VSS - 0.3 to VDD + 0.3V; (4)IVDD, Total Current into VDD (source): 80mA; (5)IVSS, Total Current out of VSS (sink): 100mA; (6)Tj, Junction Temperature: 150 °C; (7)TSTG, Storage Temperature: -60 to 150°C.

Features

st62e65cf1 features: (1)3.0 to 6.0V Supply Operating Range; (2)8 MHz Maximum Clock Frequency; (3)-40 to +125°C Operating Temperature Range; (4)Run, Wait and Stop Modes; (5)5 Interrupt Vectors; (6)Look-up Table capability in Program Memory; (7)Data Storage in Program Memory: User selectable size; (8)Data RAM: 128 bytes; (9)Data EEPROM: 128 bytes (none on ST62T55C) User Programmable Options; (10)8 I/O lines can sink up to 30mA to drive LEDs or TRIACs directly; (11)8-bit Timer/Counter with 7-bit programmable prescaler; (12)8-bit Auto-reload Timer with 7-bit programmable prescaler (AR Timer); (13)Digital Watchdog; (14)Oscillator Safe Guard; (15)Low Voltage Detector for Safe Reset; (16)8-bit A/D Converter with 13 analog inputs; (17)8-bit Synchronous Peripheral Interface (SPI); (18)On-chip Clock oscillator can be driven by Quartz Crystal Ceramic resonator or RC network.
