Product Summary

The um7108f is a pin diode. The um7108f offers moderately high power handling in combination with reasonably low levels of both series resistance and capacitance. The um7108f offers the lowest series resistance, but the highest capacitance of the group.

Parametrics

um7108f absolute maximum ratings: (1)A: 10 W, 15 ℃/W; (2)B&E: 5.5 W, 27.5 ℃/W; (3)C: 10 W, 15 ℃/W; (4)D: 7.5 W, 20 ℃/W; (5)All Packages: 35 KW; (6)Operating and Storage Temperature Range: -65 to +175 ℃.

Features

um7108f features: (1)Voltage rating to 1000 V; (2)Wide variety of package styles; (3)Rated average power dissipation to 10 W; (4)Cost effective in volume applications.

Diagrams

um7108f block diagram
