N80C196MC

N80C196MC, 16-bit MCS96 microcontroller, 7.0 V, 16 MHz, 1.5 W, PLCC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $4.00~6.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 500 :	6.00 / Piece
501 ~ 1000 :	5.00 / Piece
1001 ~ 3000 :	4.00 / Piece

PartNumber:: N80C196MC

Brand:: Intel Corporation - Intel | Pack: PLCC | D/C: 13+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-13

From Other Seller

Part Number:N80C196MC
US $4.00 - 6.00
Quantity:

piece

Product Summary

The N80C196MC is a 16-bit MCS96 microcontroller. The N80C196MC is designed primarily tocontrol three-phase AC induction and DC brushless motors. The N80C196MC features an enhanced three-phase waveformgenerator specifically designed for use in inverter motor-control applications. This peripheral provides pulsewidthmodulation and three-phase sine wave generation with minimal CPU intervention. The N80C196MC generates threecomplementary non-overlapping PWM pulses with resolutions of 0.125μs (edge triggered) or 0.250μs(centered).

Parametrics

N80C196MC absolute maximum ratings: (1)Storage Temperature: – 65°C to + 150°C; (2)Ambient Temperature under Bias: – 40°C to + 85°C; (3)Voltage from VPP or EA# to VSS or ANGND: – 0.5 V to + 13.0 V; (4)Voltage with respect to VSS or ANGND: – 0.5 V to + 7.0 V; (5)Power Dissipation: 1.5 W; (6)FOSC (Oscillator Frequency): 8 MHz to 16 MHz.

Features

N80C196MC features: (1)High Performance CHMOS 16-bit CPU; (2)16 MHz Operating Frequency; (3)32 Kbytes of On-chip OTPROM/ROM; (4)744 Bytes of On-chip Register RAM; (5)Register-to-register Architecture; (6)16 Prioritized Interrupt Sources; (7)Peripheral Transaction Server (PTS) with 15 Prioritized Sources; (8)Up to 52 I/O Lines; (9)3-phase Complementary Waveform Generator; (10)8-channel 8- or 10-bit A/D with Sample and Hold; (11)2-channel UART; (12)Event Processor Array (EPA) with 2 Highspeed Capture/Compare Modules and 4 Highspeed Compare-only Modules; (13)Two Programmable 16-bit Timers with Quadrature Counting Inputs; (14)Two Pulse-width Modulator (PWM) Outputs with High Drive Capability; (15)Flexible 8- or 16-bit External Bus; (16)1.75 μs 16 × 16 Multiply; (17)3 μs 32/16 Divide; (18)Extended Temperature Available; (19)Idle and Powerdown Modes; (20)Watchdog Timer.
