ATMEGA128RFA1-ZU

microcontroller, 14.5mA, 3.6V, 64QFN

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.20~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 800 :	2.40 / Piece
801 ~ 1600 :	2.20 / Piece

PartNumber:: ATMEGA128RFA1-ZU

Brand:: ATMEL Corporation - ATMEL | Pack: | D/C:

Availability:: Supply Ability: 8000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-23

From Other Seller

Part Number:ATMEGA128RFA1-ZU
US $2.20 - 2.50
Quantity:

piece

Product Summary

The ATMEGA128RFA1-ZU is a low-power CMOS 8 bit microcontroller based on the AVR enhanced RISC architecture combined with a high data rate transceiver for the 2.4 GHz ISM band. The ATMEGA128RFA1-ZU is derived from the ATmega1281 microcontroller and the AT86RF231 radio transceiver. Applications of the ATMEGA128RFA1-ZU include: ZigBee/IEEE 802.15.4-2006/2003 Full And Reduced Function Device (FFD/RFD) , General Purpose 2.4GHz ISM Band Transceiver with Microcontroller, RF4CE, SP100, WirelessHART, ISM Applications and IPv6/6LoWPAN.

Parametrics

ATMEGA128RFA1-ZU absolute maximum ratings: (1) (1) Ultra Low Power consumption (1.8 to 3.6V) for Rx/Tx AVR: <18.6mA; (2) CPU Active Mode (16MHz): 4.1mA; (3) 2.4GHz Transceiver; (4) Deep Sleep Mode: <250nA @ 25°C; (5) Speed Grade: 0-16MHz @ 1.8-3.6V; (6) Temperature Range: -40 to 85°C.

Features

ATMEGA128RFA1-ZU features: (1) High Performance, Low Power AVR 8-Bit Microcontroller; (2) Advanced RISC Architecture; (3) Non-volatile Program and Data Memories; (4) JTAG (IEEE std. 1149.1 compliant) Interface; (5) Advanced Interrupt Handler; (6) Watchdog Timer with Separate On-Chip Oscillator; (7) Power-on Reset and Low Current Brown-Out Detector; (8) Advanced Power Save Modes; (9) Fully integrated Low Power Transceiver for 2.4 GHz ISM Band; (10) Hardware Security (AES, True Random Generator) .
