Product Summary

The fzh135 is a Platinum DRAGON Lead (Pb) Free Product. It is ideal for: (1)TFT backlighting for large area TV applications; (2)backlighting (LCD, switches, displays, illuminated advertising, general lighting); (3)interior automotive lighting (e.g. dashboard backlighting, etc.); (4)substitution of micro incandescent lamps; (5)marker lights (e.g. steps, exit ways, etc.); (6)RGB - strobe light; (7)signal and symbol luminaire.


Parametrics

fzh135 absolute maximum ratings: (1)Betriebstemperatur Operating temperature range Top: – 40 to + 125 °C; (2)Lagertemperatur Storage temperature range Tstg: – 40 to + 125 °C; (3)Sperrschichttemperatur Junction temperature Tj: > 150 for short term applications °C; (4)Sperrschichttemperatur Junction temperature Tj: 135 °C; (5)Forward current (max.)(TA =25°C)IF: 1000 mA; (6)Sto?strom Surge current t ≤ 10 μs, D = 0.005, TA =25°C IFM: 2500 mA; (7)Leistungsaufnahme Power consumption (TA =25°C)Ptot: 4.6 W; (8)W?rmewiderstand 4)Seite 20 Thermal resistance 4)page 20 Sperrschicht/L?tpad Junction/solder point Rth JS: 8 K/W.

Features

fzh135 features: (1)package: white SMD package, colorless clear silicone resin; (2)typical Luminous Flux: 540 mW (deep blue); 35 lm (blue); 92 lm (true green); (3)feature of the device: point lightsource with high luminous efficiency and low space; (4)wavelength: 455 nm (deep blue),; (5)470 nm (blue), 528 nm (true green); (6)viewing angle: Lambertian Emitter (120°); (7)technology: ThinGaN; (8)optical efficiency: 21 % (deep blue), 13 lm/W (blue), 36 lm/W (true green); (9)grouping parameter: luminous flux, wavelength, radiant power; (10)assembly methods: suitable for all SMT assembly methods; (11)soldering methods: IR reflow soldering; (12)preconditioning: acc. to JEDEC Level 2; (13)taping: 24-mm tape with 800/reel, ?180 mm; (14)ESD-withstand voltage: up to 2 kV acc. to JESD22-A114-D.

Diagrams

fzh135 pin connection
