SKKD162/16

skkd162/16, Rectifier Diode Module, 0.85 V, 6000 A, Semikron International

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.30~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 500 :	2.40 / Piece
501 ~ 1000 :	2.30 / Piece

PartNumber:: SKKD162/16

Brand:: Semikron International - SEMIKRON | Pack: | D/C:

Availability:: Supply Ability: 8000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-18

From Other Seller

Part Number:SKKD162/16
US $2.30 - 2.50
Quantity:

piece

Product Summary

The skkd162/16 is a Rectifier Diode Module. The applications of the skkd162/16 include Non-controllable rectifiers for AC/AC converters, Line rectifiers for transistorized, AC motor controllers, Field supply for DC motors.

Parametrics

skkd162/16 absolute maximum ratings: (1)IFAV: 195 A; (2)ID: 90/115 A; (3)IFSM: 6000 A; (4)IT: 180000 AS; (5)VF: max.1.5 V; (6)VTO: max.0.85 V; (7)RT: max.1.2 mΩ; (8)IRD: max.9 mA; (9)RTH J-C: 0.18/0.09 K/W; (10)RTH C-S: 0.1/0.05 K/W; (11)TVJ: -40 to +135 ℃; (12)MS: 5 ± 15% Nm; (13)M: 165 g.

Features

skkd162/16 features: (1)Heat transfer through aluminium oxide creamic isolated metal baseplate; (2)Hard soldered joints for high reliability; (3)UL recgnized, file no. E63532.
