Product Summary
The ps21267-ap is an intelligent power module. The ps21267-ap integrates power devices, drivers, and protection circuitry in an ultra compact dual-in-line transfer-mold package for use in driving small three phase motors. Use of 5th generation CSTBT Chip Technology, DIP packaging, and application specific HVICs allow the designer to reduce inverter size and overall design time. The applications of the ps21267-ap include Washing Machines, Refrigerators, Air Conditioners, Small Servo Motors, Small Motor Control.
Parametrics
ps21267-ap absolute maximum ratings: (1)Power Device Junction Temperature, Tj: -20 to 125 ℃; (2)Module Case Operation Temperature, TC: -20 to 100 ℃; (3)Storage Temperature, Tstg: -40 to 125 ℃; (4)Mounting Torque, M4 Mounting Screws: 13 in-lb; (5)Module Weight (Typical): 54 Grams; (6)Self-protection Supply Voltage Limit, VCC(prot.): 400 Volts; (7)Isolation Voltage, AC 1 minute, 60Hz Sinusoidal, Connection Pins to Heatsink Plate, VISO: 2500 Volts.
Features
ps21267-ap features: (1)Compact Packages; (2)Single Power Supply; (3)Integrated HVICs; (4)Direct Connection to CPU.
Diagrams
